MFLOW 17'6

Introducing the Millard MFLOW 17’6



The Millard 17’6 MFLOW caravan is an on-road model featuring the AL-KO leaf spring suspension under an iconically “Millard” built caravan.

CHASSIS – Proudly build in-house by a second generation chassis builder, the Millard chassis use all Australian Bluescope steel. The chassis is then hot dipped galvanised to ensure longevity and peace of mind.

FUN FACT: Millard were the first caravan company in the world to offer hot dipped galvanising as a standard feature.





FRAME – Using construction methods perfected over 76 years of manufacturing, every MFLOW frame is built with quality aluminium joined with high tensile pop rivets and corner supporting gussets.

ROOF – Our 1 piece roof design using a high quality sandwich pressed composite increases insulation and strength while minimising the change of water ingress over the long term.

INTERIOR – With CNC cabinetry being used in conjunction with interior designer coordination. The interiors of our MFLOW range are far from basic. In fact they are beautiful!

EXCEPTIONAL STYLING

Select one of the interior images below to enlarge.

LAYOUT OPTIONS

Select one of the below layout option to enlarge.
(Single beds upon request)

STANDARD FEATURES

CONSTRUCTION

  • Hot Dip Galvanised Chassis.
  • Aluminium Wall Frame.
  • Full Piece sandwich pressed Composite Roof.
  • Insulation to Walls and Ceilings.
  • Marine Ply Flooring (Ask us about this feature).
  • Corrugated Cladding Silver or White.
  • Alko Leaf Spring suspension.

EXTERIOR

  • 15 inch wheels.
  • Pull Out Step.
  • Vinyl Decals – Gold , Red, Blue or Silver.
  • 2 x 95 litre Water Tanks.
  • Provision for Grey Water Tank.
  • Black Checker Plate sides.
  • Picnic Table
  • Mains Tap to A Frame & Mains Pressure.
  • 2x 9kg Gas Bottles.
  • 1x 150w Solar Panel with Regulator.
  • Dometic External roll out Awning.
  • Annexe Light.
  • Gas Bayonet.
  • External Power Point and TV Point.
  • Entry Door with Light.
  • Rear bar with spare wheel.

INTERIOR

  • CNC Cabinetry.
  • 1x 105ah Battery (under bed).
  • USB and power outlets throughout.
  • Radio/CD Player.
  • IBIS 4 Air Conditioner.
  • Thetford 150 Litres Fridge.
  • Recessed Dometic 4 Gas Cooktop with Grill.
  • L-Shaped Lounge.
  • Microwave.
  • Slimline RangeHood.
  • Front Loader Washing Machine.
  • 28ltr Swift hot water service.
  • Winegard HD Antenna.
  • 24″ LED TV/DVD combo.
  • Stainless steel kitchen sink.
  • Ensuite – White Round Basin.
  • Ensuite- Chrome Shower Taps.
  • Kitchen Table with TIC Cushion.
  • 2x Reversible Exhaust Hatches with LED lights.

SAFETY

  • Breakaway Safety System.
  • Fire Extinguisher.
  • Smoke Alarm.
  • Door – External 4 pin lock with security screen.

APPROXIMATE WEIGHTS

TARE: 2095 kg

ATM: 2500 kg

BALL: 185 kg

GTM: 2315 kg

PAYLOAD: 405 kg

Weights are a dry estimate based off previous build with standard inclusions only.
